10005 SL
Voltage Range
44V - 50V ( 12S LiPo)
Motor Weight
277 g ± 2 g
Propeller Size
30 " inch to 32 " inch
Kv (Motor Velocity Constant) :
90 RPM/V
Kt (Motor Torque Constant) :
0.1468 Nm/A @ 2542 RPM
Maximum Continuous Current :
12.69 A (180s)
Maximum Continuous Power :
626.3 W (180s)
Power Density :
2.26 W/g (Rated), 4.84 W/g (Maximum)
Voltage Range :
44V - 50V ( 12S LiPo)
Io (XX@V) :
0.96 A (48@V)c
Inductance per phase (Winding Inductance) :
0.182 ( ≃0.03) mH
Stator Poles :
36S
Magnetic Poles :
40P
Bearings :
Single 61803- 2z Sealed
Stick Out Shaft Diameter :
ø 0 mm
Motor Diameter :
ø 107 mm
Motor Length :
23 mm
Motor Weight :
277 g ± 2 g
Mount Pattern @ 90 deg :
4 X M4 @ PCD ø 23 mm ↧ 7.5 mm
Compatible Propeller Size :
30 " inch to 32 " inch
Propeller Mount Pattern :
4 X M4 @ PCD ø 32 mm ↧ 8 mm
Specifications And Performace Data
