6040 FW
Motor Diameter
ø 80 mm
Motor Length
67 mm
Motor Weight
865 g ± 2 %
Kv (Motor Velocity Constant) :
160 RPM/V
Kt (Motor Torque Constant) :
0.0843 Nm/A @ 3918 RPM
Maximum Continuous Current :
52A (180s)
Maximum Continuous Power :
2391 W (180s)
Power Density :
2.76 W/g (Rated), 5.76 W/g (Maximum)
Voltage Range :
44V - 50V ( 12S LiPo)
Io (XX@V) :
3.7A (48@V)
Inductance per phase (Winding Inductance) :
0.027 ( ≃0.03) mH
Stator Poles :
24S
Magnetic Poles :
28P
Bearings :
Triple (2 x 619/6-2Z Sealed , 1 x 628/8-2Z Sealed)
Stick Out Shaft Diameter :
M 10 LH
Motor Diameter :
ø 80 mm
Motor Length :
67 mm
Motor Weight :
865 g ± 2 %
Mount Pattern @ 90 deg :
4 X ø 5.3 @ PCD ø 90 mm ↧ THRU mm
Compatible Propeller Size :
28 " inch to 30 " inch
Propeller Mount Pattern :
M 10 LH
Specifications And Performace Data
