6020 PRO
Motor Diameter
ø 4.8 mm
Motor Length
42 mm
Motor Weight
425 g ± 5 g
Kv (Motor Velocity Constant) :
180 RPM/V
Kt (Motor Torque Constant) :
0.068 Nm/A @ 5291 RPM
Maximum Continuous Current :
47A (180s)
Maximum Continuous Power :
2209W (180s)
Power Density :
3.53 W/g (Rated), 6.86 W/g (Maximum)
Voltage Range :
44V - 50V ( 12S LiPo)
Io (XX@V) :
2.5A (48@V)
Inductance per phase (Winding Inductance) :
0.046 ( ≃0.03) mH
Stator Poles :
24S
Magnetic Poles :
28P
Bearings :
Triple 626 -2Z Sealed
Stick Out Shaft Diameter :
ø 6 mm
Motor Diameter :
ø 4.8 mm
Motor Length :
42 mm
Motor Weight :
425 g ± 5 g
Mount Pattern @ 90 deg :
4 X M3 @ PCD ø 20 mm ↧ 6 mm
Compatible Propeller Size :
22 " inch to 26 " inch
Propeller Mount Pattern :
8 X M3 @ PCD ø18mm, ø20mm ↧6mm, 4 X M3 @ PCD ø12mm ↧3.8mm
Specifications And Performace Data
